Hydraulic hold the top device (heavy single port)

Place of origin

CHINA

Parameter

Features:
Support mandrel can be used to hold the top of the rescue scene, traction and other operations. In addition to optimize the product structure, increasing the distance and hold the top stroke. Increased space rescue.
1, double-tube single-interface design, can operate under pressure, in one step;
2, the interface is 360-degree rotation snap, the operation more convenient and more secure;
3, anti-skid control switch makes the operation more precise;
4, the internal two-way hydraulic lock, with self-locking function;
5, non-slip jaw structure ram rod head and the base of the mandrel so that the inclined surface can be smooth or stable security
6, light weight, small size, strong, excellent side load coordination, etc.
parameter:
Rated working pressure: 63MPa
Hold the top power: 110KN
Operating range: 450-750
Hold the top stroke: 300mm
Weight: ≤12kg
Dimensions (L * W * H): 450 × 90 × 170mm

Use

Rescue for various rescue operations
